Integrated CAM minimizes risk, improves quality control, reduces scrap, minimizes downtime – so more profits, better business.

One system – design through manufacturing.

Fusion 360 CAM supports 2D, 3D, 4-axis, 5-axis milling and turning in the most ease of use interface.Īdvantages of using integrated Fusion CAM.

Fusion 360 CAM processors calculations and toolpaths very fast, allowing you to make changes to the machining operations very quickly to get the right output you desire.

If you are familiar to Autodesk Inventor or AutoCAD, then you will find Fusion 360 CAM easy to use.

Fusion CAM tools allow you to quickly program machined parts inside an easy-to-use user interface.

Below is a sample of the code created which can be uploaded to the CNC machine: Brackets will be automatically installed once you select post process. Once you are happy with the simulation you can select Post Process on the Fusion CAM ribbon, pick one of the many available post configurations that Fusion CAM has to offer, select the save location and choose Post.įusion 360 CAM uses brackets for editing post processed output, post configurations and log files. Use the timeline play button to simulate the toolpaths. By simulating your toolpaths, you can make sure your part will be machined without any errors or damage to equipment. Options of show stock and stop on collision can be used.

Use the simulation tool on the CAM ribbon to simulate and verify your tool paths. Use the right tool from the Fusion CAM library, select the required CNC strategy and select the area to machine, which will generate the required tool path.

Select setup on the Fusion CAM ribbon, define the WCS stock point and stock size then select OK. Use the dashboard to open or upload an existing design or create the new design in Fusion 360 using common Autodesk Inventor tools. Here’s how you can create a complete machined part in Fusion 360 CAM in 5 easy steps: Since we keep cut load constant, you can push the tool a lot faster and deeper through the material.

If CAM is your game, then Autodesk Fusion 360 is what you need to be using right now.įusion 360 CAM has 2D, 3D, 4-axis, 5-axis and turning strategies to fulfil your needs.įusion 360 CAM also gives you the option of using 2D and 3D Adaptive clearing. Adaptive clearing calculates paths based on a sophisticated algorithm that constantly considers the remaining material and maintains optimal tool engagement throughout the cut.
